You wanted a flagship R-Series to fill larger rooms based on the trickle-down technology from the S-Series. The second-best two-channel system in our line-up still rivals most competitor’s flagship. Employing the same DPC array and long-excursion woofers for extremely low distortion and our beam forming controlled directivity down to 500Hz make this a full-range masterpiece only rivaled by our own award-winning S7t.

EXPERIENCE UNMATCHED SOUND QUALITY

Our R-Series products are available in a single, carefully selected High Gloss Black finish that complements most home interior designs. Enjoy the timeless design with exceptional performance, all in one stunning finish.

IT'S ALL IN THE DETAILS

Designed as a stand alone 2ch high fidelity speaker with the versatility to be used as part of multi-channel systems. Sharing “trickle-down” technology from our flagship S-Series, the DPC-Array here based on three 26mm domes, guarantees excellent directivity control and timbre matching with all R-Series speakers. The Silk diaphragms developed ground up, chosen specifically their smooth, effortless representation of midrange and treble. The 165mm woofers are made from our proprietary HPF pulp, two years in development, bringing new technology to one of the oldest materials used in loudspeaker design. The R7t can be aligned as bass reflex or acoustic suspension depending on specific tastes. Rich, dynamic bass matched with advanced mid/treble directivity pattern control and silky highs offer best in class performance.

TECHNICAL SPECIFICATIONS

• Enclosure alignment: 4-way bass reflex / acoustic suspension
• Driver compliment DPC-array: 26mm(3) Silk dome
• Woofers: 165mm(4) HPF diaphragms
• Sensitivity: 90.0dB / 2.83v / 1.0m
• Impedance: 4Ω nominal / 3.1Ω min
• Response Linearity: 80 - 20kHz +/-1.5dB window
• Frequency Response (-10dB): Bass reflex: 27 - 32kHz / Acoustic suspension: 38 - 32kHz
• Typical In Room bass extension: Bass reflex: 19Hz / Acoustic suspension: 30Hz
• Dimensions (HxWxD): 1268 x 230 x 350mm / 49.9 x 9.0 x 13.7"
• Weight: 48.0 kg (105.6 lbs.)
• Recommended Amplifier Power: 100 - 400W RMS
• SPL capability @1m (100-20kHz): 116.0dB peak <3% - 2nd, 3rd Harmonics
• Certification: THX Dominus, THX Ultra
• Available finishes: Piano black
