Faders & Crossfader Special Performance monorail PANASONIC FADER & CROSSFADER combined with ECLER VCA* technology. Crossfade and fade functions are reversible and slope adjustable. The HAK Crossfader now incorporates 2 metallic trimmer detents on its ends so as to reduce the cut-in-time travel and maximize the «battle» performance of the mixer. The 2 metallic pieces can be mounted into 4 positions reducing the cut-in-time travel of 0 / 0,5 / 1 or 2mm.

Fader and Crossfader Slope adjustment and Reverse switch The curves of the Crossfader and Faders are adjustable through a potentiometer with a very wide range of curves from the fastest scratch to the smoothest contour. A HAMSTER switch allows reversing the crossfade and fading function; when activated, three red led to display the Normal/Reverse position of the Fader 1, Fader 2, and/or Crossfader.

Cut switches The C&K brand CUT Switches are multidirectional, offering 8 adjustments accessible by removing the front panel.

Monitoring system For pre-fader listening, a MONITOR-MIX crossfader is active when the Pgm/Pfl switch selector is in PFL position; then direct crossfading between PFL input 1 and PFL input 2 is possible. On PGM position the mixer can be fully performed through Headphones.

Effect Send Switches The switches allow the Dj to send the PGM1 or/and PGM2 post-fader stereo signal to affect external devices through the EFF output. The already processed signal is returned to the main bus through the MIX input.

Balance One Balance short slider per channel allows the Dj to execute “Stereo-Pan-Scratches” in a fast and easy fading manipulation.

3 band EQ The HAK 320 features a High/Mid/Low Band EQ that allows the Dj to boost tones up to +10 dB and cut them down to –25/-30 dB!

Input Gain Control

Phono/Line input selectors

Microphone Channel A balanced MIC input through a combined XLR/jack input connector. Level, Bass &Treble controls in the front panel. GAIN adjust and INSERT jack 1/4" connection for external effects only in MIC input, in the back panel. The INSERT connection could be used also as LINE input.

Master Out 1 & 2 and REC output Two completely independent high-powered main program outputs. OUT 1, controlled through Master 1, is electronically balanced and with XLR3 connectors. OUT 2, controlled through Master 2, is non-balanced and with RCA-cinch connectors for monitoring or session output, and finally a recording REC output with RCA.

Session The HAK 320 features a SESSION Input that allows the DJ to organize a Mixing Session with others in a daisy chain formation. The SESSION potentiometer allows adjusting the level of the foregoing DJ connected to the HAK 320.

High power monitoring The powerful headphone amplifier guarantees enough spare power even in the noisiest environments or working with only one headphone.

VCA: Voltage Controlled Amplifier [more info] TECHNICAL CHARACTERISTICSInputs Sensitivity nom/ImpedancePHONO LINE /CD MICRO (BAL) MIX SESSION INSERT -45 dBV / 50 k -10 dBV / 50 k -50 ÷ -30 dBV / 1.5 k 0 dBV / 20 k 0 dBV / 20 k 0 dBV / 100 k Outputs Level/Minimum LoadOUT 1 OUT 2 REC HEADPHONES INSERT BAL.0(+6)* dBV@ 600 1(2) VRMS 0(+6)* dBV @ 1 k 1(2) VRMS 0 dBV / 10 k 230mW / 400 0 dBV / 100 k Input Level AdjustPHONO LINE/CD -15 ÷ -45 dBV +20 ÷ -10 dBV Frequency ResponsePHONO LINE/CD MICRO RIAA ± 0.5 dB 10 Hz ÷ 30 kHz -1 dB 10 Hz ÷ 30 kHz -1 dB Harmonic DistortionPHONO LINE/CD MICRO < 0.09 % < 0.08 % < 0.15 %CMRRMICRO > 70 dB / 1 kHzSignal Noise RatioPHONO LINE/CD MICRO > 90 dBV > 95 dBV > 75 dBV Tone ControlBASS TREBLE MID -30 / +10 dB -30 / +10 dB -25 / +10 dB Filters (cut frequency at -6dB) Slope 12 dB/oct in all the casesHIGH MID LOW 6.5 kHz 6.5 kHzand 200 Hz 200 HzMains Depending on your country(See characteristics in the back of the unit.)Power consumption15 VADimensionsPanel Depth 265 x 360 mm 80 mmWeight4.8 KgSpecial Cut-in-time adjustmentThe HAK crossfader integrates 2 metallic trimmer detents on its ends so as to reduce the cut-in-time travel and maximize the «battle» performance of the mixer. The 2 metallic pieces located under the front panel (front view) can be mounted into 4 positions reducing the cut-in-time travel of 0 / 1 / 3 or 4mm (top view).* Internally selectable
