6-String

• Weight: 7.6lbs
• Body: Profiled American Ash
• Neck heel: Special contoured for easy upper frets access
• Unique Features: Special slick bolt-on neck joint with a 6-screw mounted on ferrules, John Browne Signature Electronics Cavity Cover
• Construction: Special slick bolt-on neck joint with a 6-screw mounted on ferrules
• Scale: 25.4″ (645mm)
• Neck: 5-ply / Wenge-Maple
• Radius: 16″ (406 mm)
• Fingerboard: Ebony
• Markers & Inlays: Luminlay side dots - Super Blue 2 mm
• Neck dimensions: Width at nut – 43.5 mm, Width XII fret – 54.0 mm, Width XXIV fret – 58.0 mm, Thickness I fret – 20.0 mm, Thickness XII fret – 21.0 mm
• Truss rod: Double action truss rod, "Duvell Q" Custom Matching Truss Rod Cover
• Frets: 24 extra jumbo, Ferd Wagner 9685 Stainless Steel, Crown dimensions: 2.80 × 1.45 mm (w × h)
• Headstock: Angled; topped with Ash
• Nut: Graph Tech Black TUSQ
• Tuners layout: 3 + 3
• Pickups / Electronics: H-H / Bare Knuckle Nailbomb - ceramic magnet version (Bridge) + Cold Sweat (Neck) / - Custom Q Tyger Covers
• Control: 1 × Volume only - push-pull for coil splitting (Tone pot position), 3-way lever switch
• Knobs: Mayones Custom Knob(-s) / Monuments Wenge Dome
• Bridge: Schaller Hannes strings-thru-body
• Tuners: Hipshot Grip-Lock Locking Tuners
• Additional equipment: Schaller Security Straplocks, Switchcraft jack, John Browne Signature Electronics Cavity Cover
• Hardware color: Black
• Case: Mayones Hiscox Guitar Hardcase

7-String

• Body: Profiled American Ash
• Neck heel: Special contoured for easy upper frets access
• Unique Features: Special slick bolt-on neck joint with a 6-screw mounted on ferrules, John Browne Signature Electronics Cavity Cover
• Binding: No binding
• Construction: Special slick bolt-on neck joint with a 6-screw mounted on ferrules
• Scale: 25.4″ (645mm), 27" (687 mm) - baritone
• Neck: 5-ply / Wenge-Maple
• Radius: 16″ (406 mm)
• Fingerboard: Ebony
• Markers & Inlays: Luminlay side dots - Super Blue 2 mm
• Neck dimensions: Width at nut – 48.5 mm, Width XII fret – 61.0 mm, Width XXIV fret – 66.0 mm, Thickness I fret – 20.0 mm, Thickness XII fret – 21.0 mm
• Truss rod: Double action truss rod, "Duvell Q" Custom Matching Truss Rod Cover
• Frets: 24 extra jumbo, Ferd Wagner 9685 Stainless Steel, Crown dimensions: 2.80 × 1.45 mm (w × h)
• Headstock: Angled; topped with Ash
• Nut: Graph Tech Black TUSQ
• Tuners layout: 4 + 3
• Pickups / Electronics: H-H / Bare Knuckle Nailbomb - ceramic magnet version (Bridge) + Cold Sweat (Neck) / - Custom Q Tyger Covers
• Control: 1 × Volume only - push-pull for coil splitting (Tone pot position), 3-way lever switch
• Knobs: Mayones Custom Knob(-s) / Monuments Wenge Dome
• Bridge: Schaller Hannes strings-thru-body
• Strings: SIT - S1060 Power Wound [7-string]
• Tuners: Hipshot Grip-Lock Locking Tuners
• Additional equipment: Schaller Security Straplocks, Switchcraft jack, John Browne Signature Electronics Cavity Cover
• Hardware colour: Black (BLK)
• case: Mayones Hiscox Guitar Hardcase
• Weight: 8.5 LBS

Product specs

FAQs

What kind of music genres is the Mayones Duvell Q John Browne Signature best suited for?

The Mayones Duvell Q John Browne Signature is ideal for progressive metal and djent, thanks to its 7-string configuration and HH pickup setup, which offer a wide tonal range and clarity for complex riffs.

How does the bolt-on neck construction affect the playability of the Mayones Duvell Q John Browne Signature?

The bolt-on neck construction provides a snappy response and bright tone, enhancing articulation and making it easier to play fast, intricate passages.

What is the neck profile like on the Mayones Duvell Q John Browne Signature?

The neck features a comfortable, slim profile that facilitates fast playing and ease of access across all 24 frets, making it suitable for advanced players who require precision.

Are the pickups on the Mayones Duvell Q John Browne Signature passive or active?

The Mayones Duvell Q John Browne Signature is equipped with passive HH pickups, offering a dynamic range and rich tonal character without the need for a battery.

Is the Mayones Duvell Q John Browne Signature suitable for live performances?

Yes, the guitar's solid ash body and string-through bridge provide excellent sustain and stability, making it a reliable choice for live performances.
