Meet the Source Audio Spectrum Intelligent Filter – an audacious blend of versatility and innovations. This envelope filter pedal, teeming with functionality, is designed to add a new dimension to your guitar or bass rig. Its comprehensive range delivers everything from vintage filter effects, inspired by iconic pedals, to contemporary synth-like envelope phasers and octave effects. The Spectrum's unique ALT button transforms its 4-knob layout into eight distinct parameter controls, bringing an entire sonic palette within your reach.

This pedal is not just about its built-in capabilities, it also offers an extensive platform for sound design. Coupled with the Source Audio’s Neuro Desktop Editor or Neuro Mobile App, you can dive deeper into creating your unique soundscape.

Key Features:

• 6 envelope filter presets: vintage sounds inspired by legendary pedals, contemporary envelopes with octave-down effects and synth-like tones
• 8 different parameters adjustable via 4 knobs
• Deep sound sculpting options via Neuro Desktop Editor and Neuro Mobile App
• Accurate tracking with lightning-fast response from Spectrum's octave effects
• 128 MIDI-accessible factory presets via optional 3rd-party MIDI controller/USB host
• Stereo Inputs and Outputs: use Neuro Editor’s pan controls to route each Voice to any location in the stereo spectrum
• Universal Bypass: choose between analog-buffered or relay-based True Bypass
• Compact, roadworthy, anodized aluminum chassis
• Includes 9-volt DC power supply (300mA, negative tip; pedal draws 165mA)
• Extensive sound sculpting options offer an extremely wide range of sound design possibilities
• 25 Different filters, dual filter effects, 11 different envelope followers, 14 different LFO waveforms and 13 different distortion effects for the ultimate customization
• MIDI compatible via Source Audio Neuro Hub for even more flexibility
• Class-compliant USB-MIDI for easy plug-and-play with Mac/Windows recording software and 3rd-party MIDI controller/USB host.

Product specs

FAQs

What types of effects can the Source Audio Spectrum Intelligent Filter produce?

The Source Audio Spectrum Intelligent Filter offers various filter effects, including Tron, Dumpling, and Thrust, as well as Punch, Vocal Synth, and Octave Lead. This versatility allows for a wide range of tonal possibilities suitable for different musical styles.

Can the Source Audio Spectrum Intelligent Filter be used with both guitar and bass?

Yes, the Source Audio Spectrum Intelligent Filter is designed to work well with both guitar and bass, offering diverse filter and octave effects that enhance the tonal range of either instrument.

How is the bypass switching configured on the Source Audio Spectrum Intelligent Filter?

The pedal features relay-based true bypass switching, which can be switched to analog buffered mode, ensuring minimal signal loss when the pedal is not in use.

What kind of power supply does the Source Audio Spectrum Intelligent Filter require?

The pedal requires a 9V DC power supply, which is included with the purchase, and it uses 165mA of power.

Does the Source Audio Spectrum Intelligent Filter offer any connectivity options for external control?

Yes, the pedal includes a 1/8" input for expression or remote control, allowing for additional control over the effects parameters during live performances or studio sessions.

Is the Source Audio Spectrum Intelligent Filter suitable for live performances?

Absolutely, the pedal's compact size, versatile effects, and robust connectivity options make it an excellent choice for live performances, providing reliable and dynamic sound manipulation on stage.
