You have never had such a compact and capable loudspeaker in your system design toolbox before.

The Theory sb25 is a wide-bandwidth, high-output multi-use loudspeaker, perfect for restaurants, bars, hotels, retail stores, houses of worship and anywhere high-resolution, high-fidelity background or foreground sound is needed.

Capable of astonishing range and output, the 3.8” deep sb25 is literally a jack of all trades and will have you rethinking how you incorporate sound in your next high-value project.

sb25 SPECIFICATIONS

• Description: Compact Surface Mount Multipurpose High Output Loudspeaker System
• Operation: Passive, Requires 1 Theory Loudspeaker Controller Amp Channel
• DSP Requirements: Requires Model-Specific Theory-Certified DSP Loudspeaker Processing
• Drivers: 2 x 5" Theory Carbon Fiber Low Frequency Drivers, 1 x 1.4" Theory Advanced Polymer High Frequency Compression Driver
• Enclosure: Powder Coated and Anodized Extruded and Machined Aluminum, Fabric Grille
• Terminals: Twin Spring-Loaded Push Terminals
• Outdoor Capability: Indoor Use Only
• Mounting Points: Two Theory VersaSlotTM T-Slots Running Full Height with 4 x M5 Captive Nuts
• Optional Universal Mount Adapter, and Table Top Stand
• Bandwidth: 54Hz -23kHz, -6dB; 46Hz-24kHz, -10dB
• Coverage: 125 Degrees Conical, 160 Degrees Conical (-12dB @ 10kHz)
• Sensitivity: 94dB (LF); 108dB (HF) SPL/2.83V/1m
• Power Handling: 200W (AES); 400W (Continuous); 800W (Peak)
• Minimum Recommended Power: 50W rms
• Maximum Output: 117dB / 1m (based on AES power rating); 123dB SPL / 1m (peak)
• Nominal Impedance: 4-ohms
• Colors: Black
• Dimensions: 21.5" H x 9.5" W x 3.8" D (546mm H x 241mm W x 97mm D)
• Total Installed Depth (Z-clip Mount): 3.93" D (100mm) Including Z-Clip Mounting Brackets
• Net Weight: 23 lbs. (10.4kg)
• Included Accessories: Theory Z-Clip Mounting Brackets (male and female) for Flat Surface Mounting
