3 voice polyphonic synthesizer is great for making a lot of different noises, drum sounds but also melodic lines. MIDI note mode is also implemented so if you play by MIDI your sound settings works as 3 voice synthesizer.

Features

• subtractive or FM synthesis mode
• 3 voice polyphony
• 6 different sound for each preset
• 6 presets
• in subtractive mode: oscillator + state variable filter with cutoff and resonance ( LP,HP,BP,notch )
• in FM mode: oscillator + modulation oscillator with selectable wavetables
• LFO with adjustable rate, resolution, amount, destination on different parameters and 8 different shapes
• ADSR with impact on volume and adjustable impact to other parameters
• precise setting of oscillator, LFO and ADSR features are accessed by adjusting character knob which goes thru all possible settings of routing and wavetables
• exchange sounds between more Poly Synths by SysEx message
• 4 wavetables (sine, saw, distorted square, noise)
• 3 note playback by MIDI – velocity sensitive
• multi-timbral MIDI mode (lowest octave)
• MIDI clock support, master or slave (by receiving MIDI clock message it turns into slave mode)
• MIDI by side connectors – MIDI connector by connecting MIDI Bastl by the side
• demo video by Daniel Baum

Technical details

• dimensions: 75 x 75 x 55 mm
• powered by 9V battery, 9V DC center positive power supply or side pins
• user manual pdf
• latest source code at gitHub in the examples folder of the bastlTrinity repository
• MIDI implementation table
• assembly instructions instructable pdf

Product specs

FAQs

Is the Bastl Instruments Trinity Poly suitable for live performances?

Yes, the Bastl Instruments Trinity Poly is a compact and versatile 3-voice polyphonic synthesizer, making it ideal for live performances due to its portability and flexibility in sound creation.

Can the Bastl Instruments Trinity Poly be integrated with other MIDI devices?

Yes, the Trinity Poly features MIDI input, allowing it to be easily integrated with other MIDI-compatible devices for expanded setup possibilities.

What type of sounds can I create with the Bastl Instruments Trinity Poly?

The Trinity Poly offers a range of digital sound possibilities, from lush pads to intricate polyphonic textures, thanks to its 3-voice polyphonic capability.

Does the Bastl Instruments Trinity Poly require any special power supply?

The Trinity Poly typically operates with a standard power supply suitable for digital synths, ensuring easy setup without the need for specialized power sources.

How many voices of polyphony does the Bastl Instruments Trinity Poly have?

The Trinity Poly features 3 voices of polyphony, allowing for rich and layered soundscapes.
