Unlock a world of experimental soundscapes with the Doepfer A-196 Phase Locked Loop, a unique module in the realm of Eurorack synthesizers. Known for its intriguing ability to generate voltage based on frequency differences, this module invites musicians to explore uncharted territories of sound through trial and error. The A-196 is not for the faint-hearted but for those who enjoy the thrill of sonic surprise and creative exploration. Its 3-way tracking mode switch allows for unpredictable sonic textures, making it a staple for modular synth enthusiasts who thrive on in-the-moment experimentation.

Whether you're crafting harmonically rich textures or diving into the realm of hard-sync-like tones and robotic effects, the A-196 has you covered. Its three interconnected sections—internal VCO, phase comparator, and lowpass filter—work in harmony to create a feedback loop that can transform your sound palette. The module’s VCO offers flexible control with offset and a range switch, while the phase comparator section opens up further creative possibilities with its digital output and multiple tracking modes.

Perfect for those looking to push the boundaries of modular synthesis, the Doepfer A-196 encourages endless creativity and sonic exploration.

Key Features:

• Phase-locked loop module for Eurorack modular synthesizers
• Generates voltage based on frequency differences between oscillators
• Three main sections: internal VCO, phase comparator, and lowpass filter
• Capable of producing harmonically rich textures and robotic effects
• 3-way tracking mode switch for diverse sonic experimentation
• VCO offers offset control, CV input, and rectangle wave output
• Lowpass filter smooths phase comparator output and controls VCO pitch
• Compact size: 8HP wide, 40.3mm deep
• Power usage: 40mA (+12V), 0mA (-12V)

Product specs

FAQs

What functions does the Doepfer A-196 Phase Locked Loop module offer?

The Doepfer A-196 Phase Locked Loop module provides phase locking and frequency synchronization capabilities, featuring a Voltage Controlled Oscillator (VCO) offset and lowpass frequency controls for versatile signal processing in a modular synthesizer setup.

How does the Doepfer A-196 integrate into a Eurorack system?

The Doepfer A-196 requires a standard Eurorack case and power supply, occupying 8HP of rack space and consuming +12V/40mA of power, making it compatible with most Eurorack modular systems.

What are the main controls on the Doepfer A-196 Phase Locked Loop module?

The Doepfer A-196 features VCO Offset and Lowpass Frequency controls, allowing users to adjust the phase and frequency characteristics of the module's signal processing capabilities.

Can the Doepfer A-196 Phase Locked Loop module be used for audio signal processing?

Yes, the Doepfer A-196 is designed for audio signal processing within a modular synthesizer context, offering phase locking and frequency synchronization for creative sound design.

What is the depth of the Doepfer A-196 Phase Locked Loop module?

The Doepfer A-196 has a depth of 1.58 inches (40.3mm), making it suitable for most Eurorack cases with standard depth requirements.
