The Drawmer DL441 Compressor/Limiter is a dynamic powerhouse packed into a compact 1U rack space, offering four channels of sophisticated control over your sound. Perfect for both studio recording and live sound environments, this versatile processor is built to handle the unpredictable with its proprietary Auto Compressor technology. Each channel provides precise management of dynamic range, featuring an automatic attack and release system that adapts to your audio, ensuring crisp transients without unwanted peaks.

Whether you're working with complex mixes or individual instruments, the DL441's flexible compression modes—switchable between hard and soft knee—allow for tailored audio shaping. The unit also includes a variable threshold Peak Level limiter for robust output control, ensuring your signal remains clean and distortion-free, even at high levels. Comprehensive LED metering gives you instant feedback on gain reduction and signal levels, while balanced XLR I/Os and a hardwired bypass offer seamless integration into any audio setup.

Engineers will appreciate the DL441’s ability to operate each channel independently or in stereo-linked pairs, making it adaptable to a wide range of applications, from broadcast to sound reinforcement. With its globally compatible power supply, this processor is ready to go wherever your music takes you.

Key Features:

• Four-channel 1U rack space design
• Proprietary auto compressor with slope-based attack and envelope-following release
• Switchable hard knee or soft knee compression
• Four zero overshoot limiters (+20dB)
• Integrated circuit VCA
• Proprietary log level detector (not RMS)
• Full LED metering
• Selectable operating level (+4/-10 dBu)
• Balanced XLR I/O
• Hardwired bypass function

Owner's manual

Product specs

FAQs

How many channels does the Drawmer DL441 Compressor/Limiter have?

The Drawmer DL441 features four channels, making it suitable for multi-channel processing in studio environments.

What type of compression does the Drawmer DL441 use?

The Drawmer DL441 utilizes VCA (Voltage Controlled Amplifier) compression, known for its precision and versatility in dynamic range control.

What are the main controls available on the Drawmer DL441?

The Drawmer DL441 offers controls for Threshold, Ratio, Gain, and Peak Level, allowing for detailed adjustment of compression settings.

What is the frequency response range of the Drawmer DL441?

The frequency response of the Drawmer DL441 ranges from 12Hz to 35kHz, ensuring it can handle a wide spectrum of audio frequencies.

What are the input and output connections on the Drawmer DL441?

The Drawmer DL441 features four XLR inputs and four XLR outputs, providing professional-grade connectivity for studio setups.

Can the Drawmer DL441 be used as a limiter?

Yes, the Drawmer DL441 can function as a limiter by setting a high compression ratio, effectively controlling peak levels to prevent audio clipping.
