Flagship MIDI controller that connects directly to both traditional 5-pin and 1/4 inch MIDI devices. COMPACT - Allowing for easy integration into pedalboards and rigs - 224mm x 125mm x 50mm

The MC8 rewrites the rules of hands-free MIDI control, allowing you to connect directly to both traditional 5-pin and 1/4 inch MIDI devices. With 4 brand new Omniports, you decide whether each 1/4 inch port acts as a MIDI output, Aux switch input or Expression pedal input. 30 dual-paged banks of 8 switches give you quick access16 fully programmable presets simply by pressing [B+C] to toggle page.

CONTROL ANYTHING WITH MIDI As are all Morningstar MIDI controllers, the MC8 is compatible with and able to control any device that accepts MIDI. With the new Omniports, you are now free to also connect directly to 1/4 inch MIDI devices for even more control possibilities.

FULLY PROGRAMMABLE 30 dual-paged banks with 8 switches Quickly access 16 presets per bank simply by toggling

MIDI MESSAGES TYPES Each switch can send up to 16 different MIDI messages through 16 different MIDI channels. Choose from a wide range of useful MIDI message types including PC, CC, Note on/off, SysEx, MIDI Clock (preset or tap), Preset Scroll, Bank Up/Down, Toggle Page and more.

4 OMNIPORTS 1/4 inch MIDI Out, Aux Switch Input or Expression Pedal Input The choice is yours

5-PIN MIDI IN Receive MIDI messages to control the MC8 Receive messages from other devices and relay them through the 1/4 inch and 5-pin MIDI outputs

5-PIN MIDI OUT Send MIDI messages from the MC8, and relay messages received through the MIDI IN port Phantom power via pins 6 & 7

LARGE LCD DISPLAY Interactive real-time visual feedback on important information such as current bank, active preset and expression pedal position

USB CLASS COMPLIANT Drivers not required With MIDI over USB, control your DAWs and software like Ableton Live and Logic Pro USB - Send MIDI messages over USB to your PC, Mac, phone or tablet Also you can power the MC8 via USB 9VDC IN - Power the MC8 with a 9-12VDC power supply Requires at least 250mA

EASY EDITING Easily program the MC8 on the device itself, or with the Morningstar MIDI Editor for windows or OSX Programming the MC8 has never been easier

Product specs

FAQs

How many devices can the Morningstar MC8 MIDI Foot Controller control simultaneously?

The Morningstar MC8 can control up to 16 devices simultaneously, making it ideal for complex setups where multiple MIDI devices need to be managed.

Can the Morningstar MC8 be powered via USB?

Yes, the Morningstar MC8 can be powered via USB, providing flexibility for different power setups and making it convenient for use in various environments.

Does the Morningstar MC8 support custom MIDI commands?

The Morningstar MC8 supports custom MIDI commands, allowing users to program specific actions and tailor the controller to their unique performance needs.

What kind of display does the Morningstar MC8 have?

The Morningstar MC8 features a large LCD screen, which provides clear visibility of presets, commands, and other essential information during use.

Is the Morningstar MC8 compatible with expression pedals?

Yes, the Morningstar MC8 is compatible with expression pedals, offering additional real-time control over parameters for more dynamic performances.
