Step into the world of modular synthesis with the Behringer 1630 Bode Frequency Shifter Eurorack Module, a faithful homage to the legendary '70s design. This analog frequency shifter doesn't just replicate the past; it elevates your sound to new dimensions with its powerful ability to shift the entire frequency spectrum of any signal by ±5kHz. Harness the vintage charm and modern flexibility of the voltage-controlled beat frequency quadrature oscillator, ensuring every note resonates with a rich, analog warmth.

The 1630 Bode is equipped to meet the needs of both the vintage enthusiast and the modern sound pioneer. Its comprehensive controls include a Scale knob for switching between linear and exponential frequency changes, a Squelch Threshold to minimize carrier bleed, and the innovative Mixture knob that allows for creative stereo textures by combining shifted and inverted frequency outputs. With extensive CV inputs and outputs, this module invites you to experiment and redefine your sonic palette.

Designed to integrate seamlessly into any Eurorack setup, the 1630 Bode is easy to install and ready to collaborate with your existing modular rig. Whether you're crafting immersive soundscapes or pushing the boundaries of what's sonically possible, this module is your ticket to a world of endless possibilities.

Key Features:

• Authentic recreation of a renowned '70s frequency shifter
• Shifts frequency spectrum ±5kHz with analog precision
• Voltage-controlled beat frequency quadrature oscillator
• Comprehensive controls: Scale, Squelch Threshold, and Mixture knobs
• Extensive CV section with 3 inputs and 4 outputs
• Compatible with standard Eurorack cases
• Power consumption: 110 mA (+12 V) / 110 mA (-12 V)

Product specs

FAQs

What is the primary function of the Behringer 1630 Bode Frequency Shifter Eurorack Module?

The Behringer 1630 Bode Frequency Shifter Eurorack Module is designed to shift the frequency of an audio signal, creating unique modulation effects and altering the harmonic content of the sound.

Is the Behringer 1630 Bode Frequency Shifter compatible with other Eurorack systems?

Yes, the Behringer 1630 Bode Frequency Shifter is a Eurorack module and is compatible with any Eurorack system that provides the necessary power supply.

How does the frequency control range of the Behringer 1630 affect sound modulation?

The Behringer 1630 offers frequency controls ranging from -5 to +5 kHz, allowing for extensive modulation possibilities by shifting the frequency spectrum of the input signal.

What are the power requirements for the Behringer 1630 Bode Frequency Shifter?

The Behringer 1630 requires a Eurorack case and power supply, with power usage specifications of ±12V DC at 110mA.

What types of inputs and outputs does the Behringer 1630 Bode Frequency Shifter have?

The Behringer 1630 features 1 x 1/8" signal input, 1 x 1/8" control input, 2 x 1/8" outputs (A, B), and 2 x 1/8" mix outputs for versatile connectivity options.
