For synth enthusiasts looking to seamlessly integrate digital and analog worlds, the Intellijel MIDI 1U offers a robust solution. This USB-MIDI and DIN-MIDI interface module is designed for Eurorack modular synthesizers, allowing you to control your rig using a DAW, smartphone, tablet, or hardware MIDI device. Versatility is at the heart of the MIDI 1U, with its capability to reconfigure CC and Mod jacks for channel aftertouch or high-resolution MIDI, providing a smoother, more analog-style operation from digital sources.

With the ability to connect up to four Intellijel 1U MIDI expander modules, your Eurorack setup can be more dynamic and responsive than ever. A powerful processor and 14-bit DAC ensure low-latency performance, making it a reliable choice for real-time sound manipulation. Whether you're triggering envelopes or syncing your modules with your DAW, the Intellijel MIDI 1U is equipped to handle the job.

For those whose Eurorack cases lack MIDI I/O ports, pairing it with the uMIDI Jacks 1U module ensures full connectivity. The module's firmware is conveniently updatable via USB, keeping your setup future-proof and adaptable to evolving musical landscapes.

Key Features:

• USB-MIDI and DIN-MIDI interface for Eurorack modular synthesizers
• Requires 1U-compatible Eurorack case/power supply
• Clock output with divider
• 14-bit DAC and powerful processor for low-latency performance
• Configurable reset jack for syncing with DAW or hardware sequencer
• Gate and Trigger outputs, CC and Mod wheel outputs for modulation
• Firmware updatable via USB
• Power Usage: 34mA (+12V) / 2mA (-12V)
• Module Width: 14HP
• Module Depth: 14mm

FAQs:

What is the Intellijel MIDI 1U and what does it do?
The Intellijel MIDI 1U is a compact MIDI-to-CV/Gate interface for the Intellijel 1U Eurorack format. It converts MIDI messages from external gear into control voltages and gates, letting you control your modular synth from a DAW, keyboard, or hardware sequencer.

What features does the MIDI 1U offer? - Converts MIDI to CV, Gate, Velocity, Trigger, Mod Wheel, and an assignable Control Change
- Outputs MIDI Clock and Reset signals
- High-resolution 16-bit DAC for precise pitch control
- Configurable outputs via software for CC mapping, polarity, and more
- Dual Mode to control two separate voices
- Learn function for quick MIDI channel assignment
- Expandable with up to four CVx 1U modules for additional CV outputs
- Fits in the 1U row of Intellijel 7U and Palette cases

How do I connect MIDI to the MIDI 1U?
The module connects to your system’s MIDI input via an internal ribbon cable. You can use:
- The rear-panel MIDI/USB ports on Intellijel cases
- The optional MIDI IN Jacks 1U module, which provides a 5-pin DIN input

Is it compatible with other 1U formats?
The MIDI 1U uses Intellijel’s specific 1U format. It is not compatible with other 1U tile systems like those from Pulp Logic or Synthrotek. Make sure your case supports Intellijel’s 1U standard before installing.

What MIDI messages does it convert?
The MIDI 1U can process and convert:
- Note On/Off to Gate and Trigger
- Pitch Bend
- Mod Wheel (CC#1)
- Assignable CC or Channel Aftertouch
- MIDI Clock with division
- MIDI Start/Stop/Continue to Run/Reset
- Velocity to CV

What are the physical specs and power requirements?
- 14HP wide
- Approximately 32mm deep
- Draws about 34mA on +12V and 2mA on -12V
It does not require a +5V supply.

Can I use it with a MIDI keyboard or external sequencer?
Yes. Just connect your MIDI controller or sequencer to the MIDI input (via the case’s rear jack or the MIDI IN Jacks 1U). The MIDI 1U will convert those signals to pitch CV, gates, and more for controlling your Eurorack modules.

How do I configure advanced settings?
Basic setup like MIDI channel selection can be done using the Learn button on the front panel. For more detailed configuration, you can connect the module to a computer and use the Intellijel Config app to:
- Assign specific CC numbers
- Adjust trigger lengths and pitch bend range
- Change clock divisions
- Enable Dual Mode
- Customize output polarity and functions

Is this module beginner-friendly? Yes. The MIDI 1U is a great starting point for modular users who want to connect MIDI gear to their Eurorack system. It’s compact, intuitive, and packed with essential features for MIDI-to-CV conversion.

Product specs

FAQs

What is the primary function of the Intellijel MIDI 1U module?

The Intellijel MIDI 1U module serves as a MIDI voice, clock, and sync interface for Eurorack systems, allowing you to integrate MIDI devices with your modular setup.

Does the Intellijel MIDI 1U module require any specific case or power supply?

Yes, the Intellijel MIDI 1U requires a 1U compatible Eurorack case and power supply to function properly.

How does the Intellijel MIDI 1U module connect to other MIDI devices?

The Intellijel MIDI 1U module connects to other MIDI devices through its MIDI input, allowing seamless integration into your modular system for voice and clock synchronization.

What is the depth and size of the Intellijel MIDI 1U module?

The Intellijel MIDI 1U module has a depth of 1.33" (34mm) and occupies 14HP in a 1U Intellijel format within your Eurorack case.

What are the power requirements for the Intellijel MIDI 1U module?

The Intellijel MIDI 1U module requires +12V/34mA and -12V/2mA power, which must be supplied by a compatible Eurorack case.
