The Radial Pro D8 is a high-performance 8-channel direct box, designed to connect keyboards and pre-recorded tracks to any PA system. Its robust rackmount construction is perfect for both studio and live performance settings. It boasts redundant inputs for each channel, providing a seamless backup during live performances.

With two A-B 1/4" inputs per DI channel, main and back-up sources can share the same effects for each channel. The output panel features a XLR connector, a -15dB input pad selector, and a ground lift switch, ensuring clean and noise-free signal transmission.

What sets the Radial Pro D8 apart is its eight custom-made Radial transformers. These provide a linear response from 20Hz to 18kHz and are capable of handling dynamic levels from digital samplers and drum machines without distortion. In addition, the transformers are encased in a mu-metal-nickel outer shield, reducing interference from external magnetic fields and minimizing phase distortion.

For added flexibility, the Radial Pro D8 comes with a set of reversible rack ears, allowing the 1/4" input panel or the XLR output panels to be positioned at the front or back as per the sound engineer’s preference.

Key Features:

• 8-channel high-density rackmount direct box
• Two A-B 1/4" inputs per DI channel for main and back-up sources
• Throughput for personal monitoring and an effects loop
• XLR connector, -15dB input pad selector, and ground lift switch on the output panel
• Eight custom-made Radial transformers for linear response and distortion-free sound
• Mu-metal-nickel outer shield on transformers to reduce interference and phase distortion
• Reversible rack ears for flexible setup
• Ideal for interfacing keyboards and pre-recorded tracks with any PA system

Owner's manual

Product specs

FAQs

How many instruments can the Radial Pro D8 accommodate simultaneously?

The Radial Pro D8 can accommodate up to eight instruments simultaneously, as it features eight channels of passive direct box functionality.

Does the Radial Pro D8 offer any attenuation options for high-output instruments?

Yes, the Radial Pro D8 includes a -15dB pad switch on each channel, allowing you to attenuate high-output instruments to prevent overloading the input.

Can the Radial Pro D8 help reduce hum and buzz in my audio signal?

The Radial Pro D8 features a ground lift switch on each channel, which can help eliminate ground loop hum and buzz in your audio signal.

Is the Radial Pro D8 suitable for both live and studio applications?

Yes, the Radial Pro D8 is designed for both live and studio environments, offering reliable and transparent signal conversion for multiple instruments.

What types of outputs are available on the Radial Pro D8?

The Radial Pro D8 provides 8 XLR outputs and 8 1/4" thru outputs, allowing seamless integration with various audio systems and setups.
