Description

Overview

  • New ATC designed and built 25mm soft dome HF unit with precision alloy wave guide.
  • 125mm ATC mid-bass unit with integral soft dome.
  • In-house, hand-wound ribbon wire mid-bass voicecoil.
  • Massive optimised mid-bass motor assembly.
  • Flat impedance curve allowing easy load for amplifiers.
  • Veneered Finish Options – Cherry, Black Ash.
  • Painted Finish Options – Satin Black, Satin White.
  • 6 year warranty.

Specifications

  • Drivers: HF ATC 25mm Neodymium Soft Dome, Mid/LF ATC 125mm SC
  • Matched Response: ±0.5dB
  • Frequency Response (-6dB): 60Hz-22kHz
  • Dispersion: ±80° Coherent Horizontal, ±10° Coherent Vertical
  • Sensitivity: 84dB @ 1W @ 1metre
  • Max SPL: 103dB
  • Recommended Power Amplifier: 75 to 300 Watts
  • Nominal Impedance: 8 Ohm
  • Crossover Frequency: 2.5kHz
  • Connectors: Binding Posts/4mm Plugs, bi-wire
  • Cabinet Dimensions (HxWxD): 300 x 174 x 215mm / 11.81 x 6.85 x 8.46″ (grill adds 28mm depth)
  • Weight: 7.5kg
陳寗 NingSelect

陳寗 NingSelect

十萬級兩聲道 Hi-End 音響怎買?ATC SCM7高頻砍掉重練成就MK3,有夠香啊!【有YT字幕】

Video thumbnail for 十萬級兩聲道 Hi-End 音響怎買?ATC SCM7高頻砍掉重練成就MK3,有夠香啊!【有YT字幕】 by 陳寗 NingSelect

十萬級兩聲道 Hi-End 音響怎買?ATC SCM7高頻砍掉重練成就MK3,有夠香啊!【有YT字幕】

陳寗 NingSelect

陳寗 NingSelect

Reviews

5.0 out of 5

Based on 1 Review and 1 Rating

5 star
4 star
3 star
2 star
1 star
adamfiregate

No need to go higher than this

The most precise, detailed 5" speaker I ever heard. The speed and balance is a dream come true.

It's almost I could touch sounds in real space.
