In some set-ups it can be advisable to use a horizontally designed speaker rather than a vertical one. Until now, such monitors were only available within the SX top line.

The A77X, due to its outstanding features, might become a true game changer: Equipped with the same advanced technologies as the A7X, it therefore is very similar to the two-way speaker. The A77X, however, distinguishes itself by much higher, compression-free maximum sound pressure levels and dynamics. Due to its power and radiation characteristics, it also is perfectly suited for both near- and midfield monitoring.

Driver technology

Like all models of the AX series, the A77X features the ADAM proprietary X-ART tweeter. The ‘X’ stands for ‘eXtended frequency response’ and thus for one of the features of the Accelerating Ribbon Technology that has been drastically improved: the frequency response. It now extends all the way up to 50kHz. In addition, the X-ART tweeter has higher efficiency and higher maximum sound pressure levels.

The two 7” woofers are identical with that of the A7X. With their large voice coils (1.5”) and powerful amplifiers, they are capable of both very high maximum sound pressure levels as well as very deep registers. The woofers do not cover the same frequency bands: while both of them are responsible for the (sub-) bass frequencies up to about 400Hz, only one of them reproduces the midrange. This prevents interferences between the two drivers.

Amplifiers / controls

Each driver has its own dedicated amplifier. A 50W A/B amp is responsible for the X-ART tweeter, while the bass-/midwoofers are driven by a 100W PWM amp each. The front panel includes a power switch and a control for the volume that retains the volume setting independently from the on/off switch.

The rear panel features several additional controls: a gain for the high frequencies (± 4dB) and two shelf filters for high and low frequencies.

To ensure greater compatibility, there are both XLR (balanced) and RCA (unbalanced) connectors.

Product specs

FAQs

What makes the ADAM Audio A77X suitable for both nearfield and midfield monitoring?

The ADAM Audio A77X features a unique horizontal design with dual 7-inch woofers and an X-ART tweeter, providing a wide frequency response and excellent stereo imaging, making it ideal for both nearfield and midfield applications.

How does the X-ART tweeter in the ADAM Audio A77X enhance sound quality?

The X-ART tweeter in the A77X offers extended frequency response up to 50 kHz and superior transient response, delivering detailed and accurate high-frequency reproduction.

Are the ADAM Audio A77X monitors suitable for mixing and mastering?

Yes, the ADAM Audio A77X monitors are designed for professional audio environments, offering precise sound reproduction and a wide frequency range, making them suitable for both mixing and mastering tasks.

How do the amplifiers in the ADAM Audio A77X affect its performance?

The ADAM Audio A77X uses two 150-watt and one 75-watt Class D amplifiers, providing high efficiency and ample power for clear and dynamic sound reproduction across all frequencies.

Can the ADAM Audio A77X be used in a small home studio?

While the A77X is powerful enough for larger spaces, it can also be effectively used in a small home studio due to its controlled dispersion and detailed sound, ensuring accurate monitoring in various room sizes.
