Experience the iconic sound of the 1970s rock 'n' roll with the BAE 1073 Rackmount Microphone Preamp & EQ with Power Supply. This definitive British preamp/EQ brings the vintage sound to your studio with its hand-wired, transformer-coupled Class A design. It's not just a replica, but a faithful recreation designed with original-spec components, including the legendary Carnhill St. Ives transformers, Elma switches, and Canford wire.

With 80dB of gain available, the BAE 1073 Rackmount ensures you can record even the most subtle sounds with your favorite ribbon mic. Dial in the preamp gain for a hint of vintage-style coloration that adds character to your tracks. The built-in highpass filter lets you roll off low-frequency content, ensuring your recordings remain clean and clear.

The 1073's renowned 3-band EQ section is a valuable tool in any audio engineer's arsenal. It's capable of enhancing anything you throw at it, delivering the punchy equalization that the original 1073 modules were famous for. The BAE 1073 Rackmount, donned in the classic RAF blue-gray, is a legend reborn.

Key Features:

• All Class A, hand-wired transformer-coupled design
• 80dB of gain on tap handles low-output ribbon mics
• Highpass filter: Off, 50Hz, 80Hz, 160Hz, and 300Hz
• 3-band EQ section
• HF: +/-16dB shelving, 12kHz fixed frequency
• MF: +/-18dB peaking, fixed Q, selectable center frequencies at 360Hz, 700Hz, 1.6kHz, 3.2kHz, 4.8kHz, and 7.2kHz
• LF: +/-16dB shelving, selectable center frequencies at 35Hz, 60Hz, 110Hz, and 220Hz
• Handles line-level inputs for added versatility
• High-impedance DI for guitar, bass, synth, and other sources
• Polarity reverse switch
• Original-spec components include Carnhill St. Ives transformers, Elma switches, and Canford wire
• Frequency response: 10Hz-55kHz (-3dB)
• Mic input impedance selector switches between 1200 and 300 ohms
• Line input impedance: 10k ohms; DI Input Impedance 150k ohms
• Output impedance: 35 ohms
• Common mode rejection ratio: 100dB min at 60Hz
• Maximum output level: +27.4 dBu at 600ohms
• Regulated linear power supply runs up to two channels

Product specs

FAQs

What are the key features of the BAE 1073 Rackmount Microphone Preamp & EQ?

The BAE 1073 features a solid-state mic/line preamp with high/low shelving EQ, a 3-band EQ with adjustable mid frequencies, and high pass filters at 50Hz, 80Hz, 160Hz, and 300Hz. It includes phantom power and offers XLR and Hi-Z inputs, making it versatile for various recording applications.

Is the BAE 1073 Rackmount suitable for vocal recordings?

Yes, the BAE 1073 is renowned for enhancing vocal recordings with its classic Neve-inspired sound, providing warmth and clarity thanks to its high-quality preamp and EQ section. It's a popular choice for professional studios aiming for rich, detailed vocal tracks.

Does the BAE 1073 Rackmount come with a power supply?

Yes, the BAE 1073 Rackmount Microphone Preamp & EQ includes an external power supply, ensuring optimal performance and reliability for studio use.

How does the BAE 1073 Rackmount compare to other preamps?

The BAE 1073 is highly regarded for its vintage Neve 1073 sound, offering exceptional warmth and musicality. Its robust build and detailed EQ section make it a standout choice for professionals seeking classic analog character in their recordings.

Can the BAE 1073 Rackmount handle both mic and line level sources?

Yes, the BAE 1073 Rackmount is designed to accommodate both mic and line level sources with its dedicated XLR inputs, providing flexibility for various recording setups.
