Introducing the HEDD Audio Type 20 MK2, a revolutionary addition to the world of studio monitors. This impressive piece of gear stands out with its innovative 3-way design, featuring a robust 7-inch woofer, a specialized 4-inch midrange driver, and HEDD's high-definition AMT tweeter. Delivering reference-grade sound quality with abundant power and dynamics, it guarantees an open sound stage even at high volume levels.

The Type 20 MK2 is equipped with HEDD's acclaimed Air Motion Transformer (AMT) tweeter, handcrafted in Berlin. This tweeter showcases impeccable transient response and ultra-high-frequency extension, offering one of the most transparent sound reproductions in the industry.

A unique feature of the Type 20 MK2 is the SHARC-powered DSP, which provides flat phase alignment, giving you an astonishing depth and spacious stereo image. This monitor also comes with HEDD's CoP (Closed or Ported) technology, allowing you to switch between maximum low-end accuracy and maximum low-end response, tailoring it to your specific needs.

Key Features:

• Innovative 3-way design with a muscular 7-inch woofer and a dedicated 4-inch midrange driver
• Air Motion Transformer (AMT) tweeter for impeccable transient response and ultra-high-frequency extension
• SHARC-powered DSP for flat phase alignment and incredible depth
• HEDD CoP technology for switching between maximum low-end accuracy and maximum low-end response
• Three Desk Filter options and two Shelving Filter options for room tailoring
• Extend mode for deeper low-frequency extension
• Adjustable Volume and Inp. Sens. (input sensitivity) for optimized output and signal-to-noise ratio
• Analog and AES digital inputs for easy system integration
• High-end, stepped aluminum potentiometers for a luxurious feel

Product specs

FAQs

What are the main connectivity options for the HEDD Type 20 MK2 studio monitor?

The HEDD Type 20 MK2 offers 2 XLR inputs for AES and analog signals and 1 XLR for AES pass-through. It also includes an RJ45 connection for advanced networking capabilities.

Is the HEDD Type 20 MK2 suitable for mixing and mastering in a professional studio?

Yes, with a frequency response of 32Hz-40kHz and a maximum peak SPL of 120dB, the HEDD Type 20 MK2 provides accurate sound reproduction, making it well-suited for professional mixing and mastering tasks.

What type of drivers does the HEDD Type 20 MK2 use?

The HEDD Type 20 MK2 features a 7" and 4" honeycomb woofer for low frequencies and a HEDD AMT (Air Motion Transformer) for high frequencies, ensuring precise and dynamic sound.

How does the tri-amped power configuration of the HEDD Type 20 MK2 benefit audio performance?

The tri-amped configuration, with each driver powered by its own 300W amplifier, ensures optimal power distribution and clarity across the frequency spectrum, enhancing overall audio performance.

Does the HEDD Type 20 MK2's front-ported design affect its placement in a studio?

Yes, the front-ported design allows for greater flexibility in placement, as it reduces the impact of wall proximity on low-frequency response, making it ideal for various studio setups.
