Capture your sound with precision and clarity using the CAD Audio Equitek e60 Cardioid Condenser Microphone. Perfectly suited for both vocal and instrumental recordings, this microphone offers versatility without breaking the bank. Thanks to its OpAmp output stage, you’ll experience a significantly reduced noise floor and higher gain, ensuring your sound remains pure and authentic. The e60 is powered by +48V phantom power, eliminating the need for cumbersome batteries.

Designed with a cardioid polar pattern, the e60 effectively minimizes ambient noise and focuses on the sound source, making it ideal for home and project studios alike. The microphone also boasts a 4-position frequency contour switch, allowing you to tailor the low-frequency response with Flat, 40Hz, 80Hz, and 120Hz settings. Whether you’re recording delicate vocals or robust instruments, the -10dB Pad switch increases headroom and reduces distortion, providing smooth, professional-quality recordings.

Key Features:

• OpAmp output stage for low noise and high gain
• Powered by +48V phantom power
• Cardioid polar pattern minimizes off-axis noise
• 4-position frequency contour switch: Flat, 40Hz, 80Hz, 120Hz
• -10dB Pad switch for increased headroom and minimized distortion
• Ideal for vocal and instrument recording
• Includes a mic stand clip and a limited 2-year manufacturer warranty

Product specs

FAQs

Does the CAD Audio Equitek e60 require phantom power to operate?

Yes, the CAD Audio Equitek e60 condenser microphone requires phantom power (P24 or P48) to function properly.

What is the primary application for the CAD Audio Equitek e60 microphone?

The CAD Audio Equitek e60 is designed for studio recording applications, ideal for capturing detailed and accurate sound from instruments and vocals.

How does the CAD Audio Equitek e60 handle high sound pressure levels?

The CAD Audio Equitek e60 can handle a maximum sound pressure level of 140dB with the attenuator engaged, making it suitable for recording loud instruments.

What is the frequency response range of the CAD Audio Equitek e60?

The CAD Audio Equitek e60 offers a frequency response range from 30Hz to 20KHz, providing a wide spectrum for capturing various sound nuances.

Does the CAD Audio Equitek e60 have any built-in filters?

Yes, the CAD Audio Equitek e60 features a selectable hi-pass filter with options at 40Hz, 85Hz, and 122Hz to reduce unwanted low-frequency noise.
