VE-CD Valve distortion pedal with an all-analog signal path brings iconic amp sounds for your pedalboard. This Copperhead valve distortion pedal recreates a classic full stack amp tone, used for the powerful sound of rock in the 80s. Can be used for overdriven tones or thick distortion. Three output modes - standard pedal, a line-level preamp, and a direct amp-sim.

The Copperhead valve distortion pedal recreates the classic full stack amp tone, used for the powerful sound of hard rock in the 80s. Use it for lightly overdriven tones or thick distortion.

Three output modes allow you to use this as a standard pedal, a line-level preamp, and a direct amp-sim using the built-in analogue cabinet simulator. Use STANDARD mode with your normal guitar rig to totally transform your amp, or use PREAMP or CAB-SIM mode while recording directly into your audio interface. In each mode, the all-analogue design and active EQ allow you to perfectly dial in the sound you need in any situation.

The Channel Link feature allows you to chain two or more Valvenergy pedals together, through the Link jack of each pedal. Using a with a standard 1/8” stereo cable will link 2 pedals, and using a stereo 1/8” splitter will link 3 or 4 pedals. This allows you to turn one pedal on while bypassing the others, as if you were switching between channels of a guitar amp.

These pedals are equipped with a high-contrast OLED display showing an oscilloscope, a visual indication of how the waveform is affected by the knob settings. This display allows shows which mode you are currently using.

• Valve distortion pedal with all-analogue signal path
• Tight and precise modern rock tones
• Powered by Nutube
• Three output modes for use as a pedal or preamp
• Selectable analogue cabinet simulator
• OLED display with oscilloscope
• Active EQ to shape your signal

INPUTS/OUTPUTS INPUT jack, OUTPUT jack, DC9V jack, LINK jack

CONTROLS GAIN knob, VOLUME knob, TREBLE knob, MIDDLE knob, BASS knob, BRIGHT switch, MODE switch

POWER SUPPLY * 1 x 9V alkaline battery or 9V center negative AC adaptor

*: The use of an AC adaptor is recommended as the unit’s power consumption is relatively high. Should you prefer to use batteries, please use the alkaline type.

CURRENT CONSUMPTION 95 mA

BATTERY LIFE Approx. 2 hours (When using the alkaline battery. This figure will vary depending on the actual conditions of use.)

DIMENSIONS (W X D X H) 72 mm x 120 mm x 55 mm/2.83″ x 4.72″ x 2.17″ (Including the switch and foot rubber)

WEIGHT 350 g/12.35 oz. (Excluding the battery)

INCLUDED ITEM 1 x 9V battery for checking operation

ACCESSORIES (SOLD SEPARATELY) AC adaptor

Taken from https://www.voxamps.co.uk/products/ve-cd on 21 May 2024

Owner's manual

Product specs

FAQs

What are the output modes available on the Vox Copperhead Drive?

The Vox Copperhead Drive offers three output modes: standard pedal mode, preamp mode, and a mode with an analog cabinet simulator, allowing for versatile integration into different setups.

How does the analog cabinet simulator on the Vox Copperhead Drive work?

The analog cabinet simulator provides a realistic amp-like response, enabling you to use the pedal directly into a PA or recording interface without the need for a physical amplifier.

What does the OLED display on the Vox Copperhead Drive show?

The OLED display features an oscilloscope that visually represents your signal waveform, allowing for precise monitoring and adjustments of your tone.

Can the Vox Copperhead Drive be used as a preamp?

Yes, the Vox Copperhead Drive can function as a preamp, making it suitable for direct connection to a power amp or for recording purposes.

Is the EQ on the Vox Copperhead Drive active or passive?

The Vox Copperhead Drive features an active EQ, providing enhanced control over your tone by allowing you to boost or cut frequencies effectively.
