The quintessential overdrive pedal!
The Maxon OD808 Overdrive is made by the same Japanese company which crafted the original overdrive circuit in a green stompbox that's been obsessed over by guitarists for the past 30 years. It uses the ident...
“I am pretty minimal when it comes to effects,” he admits, “but from time to time I like a good delay. MXR’s Carbon Copy is fantastic, and I use that sometimes. I use a Maxon OD808 as a clean boost when things need to get really heavy, and an ISP Decimator to gate everything and keep the noise down. Other effects lying around are an [MXR] EVH Phase 90, Ernie Ball Wah and Grind Customs FX Chimaera overdrive.”more
In > Boss RE-20 Space Echo (A/Mono In > B Out) > Boss TU-3 Chromatic Tuner > Moog MF Boost > MXR Distortion + > Fulltone OCD > Maxon OD808 ReIssue > MXR Blue Box Octave Fuzz > Flux Liquid Ambience > Morley ABC IN > Morley A and B out > Boss DD-20 Giga Delay > Red Custom Box Signal Kill Switch > Stereo Out to Ampsmore
On Joel Stroetzel's [website](http://www.joel-stroetzel.allaxess.com/gear/#prettyPhoto), it lists a Maxon OD808 among his gear. This pedal was also mentioned in [Killswitch Engage's Premier Guitar interview.](https://www.premierguitar.com/articles/29524-killswitch-engage-the-jackass-the-nerd?page=2) > The Maxon OD808 has been one of the biggest parts of our sound, pedal-wise. We have it on at all times for dirty tones. It compresses the output of your guitar a little bit: It tames any flubby low-end and gives you a nice thick attack, so everything seems to cut better in the mix.more
Effects are a Boss TU-2 tuner, Prescription Electronics’ Yardbox and Experience pedals, Electro-Harmonix Deluxe Memory Man, and some variety of a Tube Screamer. At the moment my favorites are the Maxon OD 808 and Voodoo Lab’s Sparkle Drive. There are a few other things I use quite often, like a Voodoo Labs Analog Chorus and Pedal Power, Prescription Electronics Germ, and either a Carl Martin compressor/limiter or Boss CS-3 compressor/sustainer.more
In this video, Middleton explains the use of his Maxon OD808 pedal. [Guitar World:](https://www.guitarworld.com/features/sylosiss-josh-middleton-i-always-try-and-balance-out-the-shreddy-stuff-with-feel-and-melody) > I mic up with an SM57 and, apart from the Maxon OD-808 boost in front tightening the low-end, that was about it.more
“This is my favourite Tube Screamer-type pedal. This is the dream one I always wanted – either this, or the Fulltone OCD. This one is used by Killswitch and As I Lay Dying – many bands in that kind of vein were advocating it. “Great saturation, it’s awesome and it makes your pinching sound great. The tone is pretty much in the middle, and I balance the gain from the actual head with the pedal, so it’s not too much.”more
"To me the OD808 is the most natural sounding tube amp-like overdrive I have ever heard. I use a Fender Twin Reverb because I like the clean headroom I get for funk and r & b. When I turn on the OD808 for my solos the tone sounds like I turned the Twin up to 10 but without the ear shattering volume of a Twin turned up to 10...just the fat, rich sound of tube-like saturation…"more
"I currently use a JVM 205 head and a Marshall 1960A cab. Pedal-wise I keep it real simple. I stack a Maxon Tube Screamer and a Hot Cake pedal for drive and more drive, then I use a Boss Chorus Ensemble for a little bit of colour and a Boss NS-2 noise suppressor to stop everything humming loads. And a Korg tuner of course. In the studio, we tended to use amp distortion rather than pedals, so for cleans we had a Fender Bassman and then for drives we stacked some Dual Rectifiers with the Marshall with the gain whacked right up. The main amp we used though was a Bogner (I forget which model), but that sounded great."more
The quintessential overdrive pedal!
The Maxon OD808 Overdrive is made by the same Japanese company which crafted the original overdrive circuit in a green stompbox that's been obsessed over by guitarists for the past 30 years. It uses the identical circuit found in the original employing the same JRC4558 IC chip for smooth, natural overdrive similar to a cranked-up tube amp. The OD808 pedal responds to the picking dynamics and nuances of your individual style while also letting the true tone of your instrument shine through.
Originally released in 1979, the Maxon OD808 pedal was one of the first tube-amp overdrive simulators to hit the market. Its smooth, creamy crunch tone caught on quickly, and helped to launch a long line of imitators. Today, the OD808 design is without a doubt the most used, most imitated and most lauded overdrive circuit of all time. The reason for this is simple--tone. Simply put, the OD808 provides the natural, mild overdrive of a tube amp without sacrificing your guitar's original tone. In addition, it can be used as a clean booster to provide increased gain without compromising the sound of your amplifier.
The secret behind the legendary "808 tone" lies in the amplifier section of its circuit. Rather than having an amplifier stage followed by a clipping stage, the OD808 uses a signal-distorting diode (Panasonic #MA150) that is located in the amplifier stage's negative feedback loop (which also contains the JRC4558 IC chip). Therefore, the OD808 distorts signal in the amplifier circuit itself which yields a smoother, milder, more natural sounding distortion than a separate clipping stage. This is also the reason that the IC type used in the circuit has such a large impact on the unit's tone. Maxon developed this unique design more than 20 years ago, and while it is commonplace nowadays, back then it was an industry first.
It should be noted that the Reissue Series OD808 uses different output resistors than the original version. After the unit's initial release it was discovered to have a high susceptibility to noise due to static electricity buildup. To improve performance, the positions of the output resistors on the reissue OD808 were reversed and their values increased in order to reduce noise levels. This circuit change has no audible affect on the sound of the unit, save for reducing the noise levels.
Whether it's used as an overdrive or a booster, the Maxon OD808 is the closest you can get to the classic sounds of rock guitar in a compact effect pedal.
"…it"s nearly impossible to dial in a bad sound. If you"re after classic blues/rock overdrive, it would be tough to pick a better pedal."
Guitar Player Magazine, May 2000
"This device is perfect if you dig the sound of your amp but wish it could go up to 11."
Guitar World Magazine, April 2000
"I"d definitely recommend the OD808 to all Tube Screamer fans."
Vintage Guitar Magazine, November 2000
"I always loved the sound of my TS808 …now I can have it all back without the paranoia and anxiety of a feared theft, all at a cheaper price than a vintage one. Bravo!"
20th Century Guitar, October 2000
Past - Present - Perfect: Reissue Series
Faithful reproductions of the legendary '70s product line, the Maxon Reissue Series Effects offer today's musician a classic sonic palette that has defined the tones of guitarists for the past three decades. Each model's circuit is 100% analog and packaged in a time-tested chassis for a lifetime of trouble-free performance. Component quality and PC board layout have been optimized to provide consistent, low noise performance without adding unnecessary coloration to your instrument's tone.
• Rugged, Lightweight Chassis: Made of cast aluminum, extremely lightweight (less than one pound) and strong. Rectangular chassis offers easy interface with other pedal types without taking up excess pedal board or rack space.
• Electronic Bypass Switching: Dual FET (electronic) silent switching with plunger-type activator switch for smooth, quiet bypass. Buffered low impedance outputs will drive long cable lengths with no signal degradation.
• AC/DC Power Operation: power using 9-volt battery (supplied) or AC adapter (Maxon AC210N optional).
• LED Power/Battery Life Indicator: Ultra bright LED indicates effect status (on/off). Dim or no LED indicates that the battery is low or not installed.
• 3-Year Warranty: Godlyke Inc. guarantees to replace or repair (at their option) this product should it suffer from defects in materials or workmanship. Coverage period is one year for moving parts (example: pots, switches, jacks) and three years for non-moving parts (example: IC's, transistors, etc.). Damages caused by accident, abuse, alteration, or misuse are not covered by this warranty. Product appearance and normal "wear and tear" (worn paint, scratches, etc.) are not covered by this warranty. No other warranty is expressed or implied.
As stated, the original "tube screamer" sound. Very warm, but very bright. Boosts much of the mids and treble end of my guitar in a way that I really like when it comes to my 6- and 7-string mahogany solidbody guitars.
I've had the Maxon OD808 Overdrive for about a month or two now and my tone has improved massively since using it. Prior to having this pedalboard, I used the 'Screamer' overdrive on my POD HD500X and it did the job but could never compare to this.
The transparency is impeccable and it really adds a nice boost to the signal where and when I want it. It works absolute wonders on my crunch channel for just pushing it a little bit more over the edge when I need it for a lead part or something of the like.
All in all, just a great overdrive pedal and would 100% recommend this to any guitarist looking for an overdrive.
This is a pedal that gives the feel of the original tube screamer from 80's, I haven't played any original made in Japan tube screamer, however I think this on matches over 90% of the description from those who have experience with the original one, especially the mid range boost that adds a lot warmth to the tone and makes you stand out from the crowd.
considering i use this almost exclusively as a boost for my Peavey 5150 and Orange Micro Dark, my review is very one-sided. however, for my uses of the 808, it is by far my favorite Tube Screamer, that i've used. it really tightens up the flubby low-end of my Mico Dark, as well as boosts the mids with the Tone knob as well. great pedal, and i would definitely recommend it to any Metal guitarist trying to get a tighter tone.
Ein Super Booster für die die einen Valveking 100 Head besitzen, viele wissen das der Head nicht grad die Power hat um mal sagen wir mal etwas Metalartiger zu sein. Der Maxon808 boostet deine Power deutlich hoch, womit man mehr Presents und Spaß daran hat.
