Introducing the Studio Projects B1 Condenser Microphone, where affordability meets performance. Whether you're a seasoned sound engineer or an aspiring musician, this microphone is designed to be your versatile companion in any recording setting. Known for its 1" 3-micron gold-sputtered large diaphragm, the B1 captures sound with exceptional clarity and minimal noise, making it an ideal choice for vocals, instruments, and even voice-over work.

Its transformerless circuit design ensures a pure audio signal, reducing unwanted interference and maintaining the integrity of your recordings. With a frequency response of 20Hz to 20kHz, the B1 delivers a natural and transparent sound profile. Adding to its versatility are two discrete 3-way switches that let you toggle between pad levels (-10dB, -20dB) and highpass filters (75Hz, 150Hz), allowing for nine operating modes to suit various recording environments and applications.

Built to cater to both professional studios and home setups, the B1 includes essentials such as a shock mount and windscreen, ensuring each session is as polished as possible. Its ability to handle high sound pressure levels up to 132 dB means it can capture loud sound sources without distortion, while maintaining a low self-noise of 12dB-A for a clean recording experience.

For those diving into the world of high-quality recording without breaking the bank, the Studio Projects B1 is a perfect fit.

Key Features:

• True 1" 3-micron gold-sputtered large diaphragm
• Cardioid polar pattern
• Frequency response: 20Hz-20kHz
• Sensitivity: -34dB (0dB=1V/Pa)
• Output impedance: <200 Ohm
• Maximum SPL: 132 dB
• Noise: 12dB-A (IEC651)
• Transformerless circuit for low self-noise
• Gold-plated 3-pin XLR connector
• Dual selectable highpass filters (75Hz & 150Hz)
• Dual selectable pads (-10dB & -20dB)
• Includes shockmount and windscreen
• Requires +48V phantom power

Owner's manual

Product specs

FAQs

Does the Studio Projects B1 Condenser Microphone require phantom power?

Yes, the Studio Projects B1 requires phantom power to operate, typically supplied by most audio interfaces or mixing consoles with +48V phantom power capabilities.

What polar pattern does the Studio Projects B1 use?

The Studio Projects B1 utilizes a cardioid polar pattern, which is ideal for capturing sound from the front while minimizing noise from the sides and rear.

Is the Studio Projects B1 suitable for recording vocals?

Yes, the Studio Projects B1 is well-suited for recording vocals, providing a clear and detailed sound due to its large-diaphragm condenser design.

What is the maximum sound pressure level (SPL) the Studio Projects B1 can handle?

The Studio Projects B1 can handle a maximum SPL of 132dB, making it capable of capturing loud sound sources without distortion.

What accessories are included with the Studio Projects B1 microphone?

The Studio Projects B1 comes with a shock mount, windscreen, and microphone pouch for protection and ease of use during recording sessions.

Does the Studio Projects B1 have any built-in filters or pads?

Yes, the Studio Projects B1 features a low cut filter at 75Hz and 150Hz, as well as -10dB and -20dB pads to manage low-frequency noise and high sound levels, respectively.
