POWER AMPLIFIER SECTION Rated Power & Load: 160W RMS into 4 Ohm

POWER @ CLIPPING: (Typically) (7% THD, 1 kHz, 120 V AC Line) 100 W RMS into 8 Ohm 160 W RMS into 4 Ohm 2 Ohm not recommended

FREQUENCY RESPONSE +0, -1 dB, 20 Hz to 20 kHz @ 130 W into 4 Ohm

TOTAL HARMONIC DISTORTION Less than 0.5%, 100 mW to 130 W RMS, 60 Hz to 10 kHz, 4 Ohm, typically below 0.2%

HUM & NOISE Greater than 85 dB below the rated power

POWER CONSUMPTION 500 watts, 50/60 Hz. 120V AC

PREAMP SECTION THE FOLLOWING SPECS ARE MEASURED @ 1 kHz WITH THE CONTROLS PRESET AS FOLLOWS: Push Bright Off (Out) Channel Select Normal (Out) Low & High (5 10 Mid @ 0 Presence 0 dB SuperSat & Post Gain @ 10 Bottom & Edge @ 0 dB Reverb @ Nominal levels are with normal gain @ 5 Minimum levels are with normal gain @ 10

PREAMP HIGH GAIN INPUT Impedance: High Z, 220K ohms Nominal input Level: -16 dBv. 150 mV RMS Minimum Input Level: -34 dBv, 20 mV RMS Maximum Input Level: 10 dBv, 3 V RMS PREAMP LOW GAIN INPUT: Impedance: High Z, 44K ohms Nominal Input Level: -10 dBv, 300 mV RMS Minimum Input Level: -28 dBv, 40 mV RMS Maximum Input Level: +16 dBv, 6 V RMS

EFFECTS SEND Load Impedance: 1K ohms or greater Nominal Output Level: -10 dBv, 0.3 V RMS

EFFECTS RETURN Impedance: High Z, 22K ohms Designed Input Level: -10 dBv, 0.3 V RMS (Switching jack providing Effects Send to Effects Return connection when not used)

PREAMP OUTPUT Load Impedance: 1K ohms or greater Nominal Output Level: 0 dBv, 1 V RMS

POWER AMP INPUT Impedance: High Z, 22K ohms Designed Input Level: 0 dBv, 1 V RMS (Switching jack providing Preamp Output to Power Amp Input connection when not used)

SYSTEM HUM & NOISE @ NOMINAL INPUT LEVEL (20 Hz to 20 kHz unweighted) 80 dB below rated power

EQUALIZATION (Normal Channel Only) Special Low, Mid & High passive type EQ Presence: +/- 15 dB @ 5 kHz, shelving (active) Push bright: +6 dB @ 2 kHz

VOICING (Lead Channel Only) Special Bottom & Edge active type EQ

EXTERNAL FOOTSWITCH FUNCTION Reverb Defeat (when reverb control is raised) Lead Channel Defeat (when selected with button)

Product specs

FAQs

What is the power output of the Peavey Special 112 amplifier?

The Peavey Special 112 amplifier has a power output of 160 watts, making it suitable for both practice and live performance settings.

What type of speaker does the Peavey Special 112 use?

The Peavey Special 112 features a 12-inch Scorpion speaker, known for delivering clear and powerful sound.

Is the Peavey Special 112 a tube or solid-state amplifier?

The Peavey Special 112 is a solid-state amplifier, which typically offers more reliability and less maintenance than tube amps.

Does the Peavey Special 112 have built-in effects?

Yes, the Peavey Special 112 includes built-in effects, providing additional versatility for shaping your sound.

How many channels does the Peavey Special 112 have?

The Peavey Special 112 has two channels, allowing for a range of tones from clean to overdriven.

Does the Peavey Special 112 feature a reverb effect?

The Peavey Special 112 is equipped with a spring reverb, adding depth and ambience to your guitar sound.
