LITTLE BROTHER TO THE COLOUR BOX

The JHS Pedals Colour Box began with a simple idea: create a pedal that sounds like plugging directly into a vintage preamp and cranking it. No amp, no speaker, just DI goodness. Well, the Colour Box became much more as we got into designing it. Thus we decided it was time to pare it down and give guitar players and bass players a simplified version that gives you the distinct compressed overdrive and fuzz sounds you’ve heard on so many classic recordings. The Crayon is just that, a powerful little box that has all the color and characteristics of a vintage studio preamp when cranked.

CONTROLS

The Crayon has controls for Master, Pre-Vol, Tilt, and a Hi-Pass toggle. The Master volume controls the overall volume of the unit, while the Pre-Vol acts as a gain control to go from a gritty preamp drive to over-the-top gated fuzz. These controls work together to create a ton of colorful tones that are extremely useful. The Tilt control is an active EQ where when set at 12 o’clock you have a flat EQ, while turning clockwise boosts highs and cuts bass, and turning counterclockwise boosts bass and cuts highs. This gives the Crayon the ability to be tailored to any rig for bass or guitar. The Hi-Pass toggle cuts your low end with a flick of the switch for the ability to cut through the mix or get lo-fi sounds. There is a dip switch on the right side of the pedal to choose either 200Hz or 750Hz cut for the Hi-Pass.

FEATURES

• Preamp DI tones from low gain grit to gated fuzz.

• Active EQ for the perfect tones on bass or guitar.

• Hi-Pass for lo-fi AM radio sounds.

• Paint with all the colors of the wind.

The JHS Pedals Crayon is without a doubt the brightest crayon in the box that will give your tone all the color you need!

THIS PEDAL REQUIRES STANDARD 9V DC NEGATIVE POWER, CONSUMES 15MA, AND MEASURES 2.6"X4.8"X1.6"

Product specs

FAQs

What kind of tones can I expect from the JHS Crayon Overdrive pedal?

The JHS Crayon Overdrive pedal delivers a wide range of tones from subtle overdrive to rich, creamy distortion. It's known for its versatility, making it suitable for blues, rock, and even heavier genres.

Is the JHS Crayon suitable for both guitar and bass?

Yes, the JHS Crayon is designed to work well with both guitar and bass, providing a dynamic response that enhances the natural tone of the instrument.

What power supply does the JHS Crayon require?

The JHS Crayon requires a 9V DC power supply, which is sold separately. It has a power usage of 100mA.

Does the JHS Crayon Overdrive pedal work well in a pedalboard setup?

Absolutely, the JHS Crayon's compact design and standard 1/4" input/output make it easy to integrate into any pedalboard setup without taking up much space.

How does the JHS Crayon compare to other overdrive pedals?

The JHS Crayon stands out with its ability to blend overdrive, distortion, and fuzz tones, offering a unique sound palette that many traditional overdrive pedals do not provide.
